FEATURES
-
Meeting the ANSI/TIA-568-C.2 Category 3, ISO/IEC11801 and EN50173-1 specification.
-
Supports T568 A&B wiring & easy installation.
-
IDC connector can accept 23-26 AWG solid and stranded cables.
-
Industry standard tools like (110 or Krone punch down tools ).
-
Wire manage hole for easy to manage wires with cable ties.
-
RoHs Compliant
ELECTRICAL & PHYSICAL SPECIFICATIONS
-
IDC Contact: 0.8mm thickness Phosphor Bronze,tin plating over nickel
-
Jack Operating life : minimum 750 insertions
-
High impact plastic housing, UL 94V-0
-
Jack Contact : Phosphor Bronze,50μinch thickness gold plated over nickel
-
IDC Operating life : minimum 200 insertions
-
PCB : FR-4,1.6mm thickness
-
Dielectric Strength : 1000V RMS for 1min
-
Insulation Resistance : 10MΩ min
-
Contact Resistance : 2mΩ per contact
-
Temperature Range : -10 C to 60 C max
-
Humidity : 10%-65%
