MATERIAL
-
Housing : White ABS High-Impact UL94V-0 Thermoplastic.
-
Shell : Copper Alloy, Tin-Lead Plated Over Copper.
-
Plastic : PBT High-Impact UL94V-0 Thermoplastic, Glass Filled 130°C.
-
Contact : Copper Alloy 3U’’ Gold-Plated RoHS Compliant.
PHYSICAL CHARACTERISTICS
-
Durability : EIA 364-09,1500 Cycles.
-
Temperature : -55°C-+85°C.
-
Humidity : 10%-90%RH.
ELECTRICAL
-
Voltage : 30 VAC
-
Current : 1.5 AMPS MIN,PER CONTACT AT 30°C T-RISE
-
Insulation Resistance : 10 Mohm MINIMUM
-
Dielectric With Standing Voltage : 300 V AC.
-
Contact Resistance : 2 ohm MAX INITIAL.
